--- title: Cell Model F25G/F50G type｜Products｜NISSIN ProSOL CO., LTD. description: This type has a small-footprint and its modular cell design offers the freedom to easily combine and configure cells to match production needs. image: https://mktg.nissin-mfg.co.jp/hubfs/nissin-mfg/en/website/assets/images/product/gseries/003/img_1.jpg --- ![logo_NISSINProSOL_1](https://mktg.nissin-mfg.co.jp/hubfs/nissin-mfg/en/website/assets/images/common/logo_NISSINProSOL_1.png) - [Home](https://mktg.nissin-mfg.co.jp/en/?hsLang=en) - [Case Study](https://mktg.nissin-mfg.co.jp/en/case/?hsLang=en) - [Solution](https://mktg.nissin-mfg.co.jp/en/solution/?hsLang=en) - [Product](https://mktg.nissin-mfg.co.jp/en/product/?hsLang=en) - [Column](https://mktg.nissin-mfg.co.jp/en/column/?hsLang=en) - [Support](https://mktg.nissin-mfg.co.jp/en/support/?hsLang=en) - [Contact us](https://mktg.nissin-mfg.co.jp/en/contact?event_en=HSmktg&hsLang=en) - EN [JP](https://mktg.nissin-mfg.co.jp?hsLang=en) - [Home](https://mktg.nissin-mfg.co.jp/en/?hsLang=en) - [Case Study](https://mktg.nissin-mfg.co.jp/en/case/?hsLang=en) - [Solution](https://mktg.nissin-mfg.co.jp/en/solution/?hsLang=en) - [Product](https://mktg.nissin-mfg.co.jp/en/product/?hsLang=en) - [Column](https://mktg.nissin-mfg.co.jp/en/column/?hsLang=en) - [Support](https://mktg.nissin-mfg.co.jp/en/support/?hsLang=en) - [Contact us](https://mktg.nissin-mfg.co.jp/en/contact?event_en=HSmktg&hsLang=en) - [Japanese](https://mktg.nissin-mfg.co.jp?hsLang=en) - [Home](https://mktg.nissin-mfg.co.jp/en/?hsLang=en) - [Product Information](https://mktg.nissin-mfg.co.jp/en/product/?hsLang=en) - Cell model F25G/F50G type ## Cell Model # F25G/F50G type This type has a small-footprint and its modular cell design offers the freedom to easily combine and configure cells to match production needs. ## Overview ### Three Cell Types Allow for Various Configurations ![Cell Model F25G/F50G type](https://mktg.nissin-mfg.co.jp/hubfs/nissin-mfg/en/website/assets/images/product/gseries/003/img_1.jpg) F25G/F50G honing cells can be combined in various configurations. Space-saving installation and adaptable cell-combination provides the flexibility to add or remove cells after initial installation allowing for flexible add/remove after machine delivery, and easy conversion boosting productivity. In such a way, these honing cells offer an unconventional solution. ## Cells ### Freely combine three cells to achieve a honing machine with improved added value The cell units enable expansion or modification after installation, providing uniqueness. ![Loading cell](https://mktg.nissin-mfg.co.jp/hubfs/nissin-mfg/en/website/assets/images/product/gseries/003/img_2.png) Loading cells are used to load the product to the process and are available in manual and automatic types, which are interchangeable. Loading cells can also be equipped with an unloading mechanism. ![Honing cell](https://mktg.nissin-mfg.co.jp/hubfs/nissin-mfg/en/website/assets/images/product/gseries/003/img_3.png) ![Return cell/Unloading cell](https://mktg.nissin-mfg.co.jp/hubfs/nissin-mfg/en/website/assets/images/product/gseries/003/img_4.png) Return cells are used to return the product to the loading position, and they are used with a manual or automatic loading cell equipped with an unloading mechanism. Unloading cells are used to unload the product, and can be selected according to the flow of the preceding and subsequent processes. #### Cell model honing machines can be freely combined to adapt to the application The cell units enable expansion or modification after installation, providing uniqueness. ### Honing cell combinations By adding honing cells, you can **reduce honing time, improve honing precision, and increase stock removal**. ![](https://mktg.nissin-mfg.co.jp/hubfs/nissin-mfg/en/website/assets/images/product/gseries/003/img_5.png) ### Using modified manual or automatic equipment By changing the loading cell, you can **switch between automatic and manual loading**. ![](https://mktg.nissin-mfg.co.jp/hubfs/nissin-mfg/en/website/assets/images/product/gseries/003/img_6.png) ### Dividing equipment for use on other production lines When the production volume changes, you can **shift the cells to other production lines and improve production volume**. ![](https://mktg.nissin-mfg.co.jp/hubfs/nissin-mfg/en/website/assets/images/product/gseries/003/img_7.png) ## Product Video ### Match Honing ## Features - ### When used in combination with honing cells, these units both boost efficiency and maintain quality control. Honing cells can be added to reduce processing time, increase precision or increase stock capacity.  - ### Loading cells are compatible with both manual and automatic equipment allowing either manual or automatic operation. - ### Overall optimization is achieved by using cell modules on other production lines. Fluctuations in production output can be managed by adding or removing cells, thereby helping to increase the production of other production lines. ## Specifications | Model | F25G | F50G | | | | | --- | --- | --- | --- | --- | --- | | Number of honing spindles | 1 | 2 | 1 | 2 | | | Honing range | Diameter | φ3～φ40 | φ4～φ100 | | | | Length | 80mm | 130mm | | | | | Driving method | For spindle rotation | Servo motor | Servo motor | | | | Spindle speed | Operating RPM range | 1～3,000rpm (Timing Belt) | 1～3,000rpm (Timing Belt) | | | | Spindle stroke | Speed | Maximum | 40m/min | 30m/min | | | Stroke | Max. stroke | 200mm | 300mm | | | | Min. setting | 0.01mm | 0.01mm | | | | | Stone expansion | Expansion method | Fixed amount expansion | Fixed amount expansion | | | | Expansion amount | Min. setting | 0.01 μm/1 expansion | 0.01 μm/1 expansion | | | | Number of honing programs | 30 | 30 | | | | | Machine weight | 2,000kg | 2,500kg | 2,000kg | 3,000kg | | | Machine dimensions | Width | 785mm | 1,285mm | 785mm | 1,285mm | | Depth | 2,190mm | 2,135mm | 2,190mm | 2,135mm | | | Overall height | 2,100mm | 2,100mm | 2,230mm | 2,230mm | | Maximum speed shown may not be available for some honing lengths and conditions. The honing length is limited by the required precision. Contact us for details. Specifications are subject to change without notice for product improvement. ## Main Applications ![Pinion gears](https://mktg.nissin-mfg.co.jp/hubfs/nissin-mfg/en/website/assets/images/common/img_1.jpg) ### Pinion gears ![Automobile connecting rods](https://mktg.nissin-mfg.co.jp/hubfs/nissin-mfg/en/website/assets/images/common/img_2.jpg) ### Automobile connecting rods ![Turbocharger housings](https://mktg.nissin-mfg.co.jp/hubfs/nissin-mfg/en/website/assets/images/common/img_3.jpg) ### Turbocharger housings ![Control valves](https://mktg.nissin-mfg.co.jp/hubfs/nissin-mfg/en/website/assets/images/common/img_4.jpg) ### Control valves ## Case Study ### [![](https://mktg.nissin-mfg.co.jp/hubfs/nissin-mfg/en/website/assets/images/case/012/img_1.jpg) Industry：Transportation component manufacturing Department：Production engineering division An Aging Machine Produced Inconsistent Measurement Results, Leading to a Decrease in Productivity What solution did the honing professional propose to ensure stable machining accuracy and increase productivity?](https://mktg.nissin-mfg.co.jp/en/case/012/?hsLang=en) ### [![](https://mktg.nissin-mfg.co.jp/hubfs/nissin-mfg/en/website/assets/images/case/011/img_1.jpg) Industry：Die component manufacture Department：Production engineering division Manufacturer Hoped to Mechanize Grinding Process but 35 Types of Die Components Made Tooling Too Expensive Honing professional proposes standardized solution requiring only six flexible diameter mandrel sizes](https://mktg.nissin-mfg.co.jp/en/case/011/?hsLang=en) ### [![](https://mktg.nissin-mfg.co.jp/hubfs/nissin-mfg/en/website/assets/images/case/010/img_1.jpg) Industry：Machine-tool component manufacturing Department：Production engineering division Internal Bore Surface Finishing Process Stood in Way of Productivity Increase New solution stabilizes precision while slashing processing times](https://mktg.nissin-mfg.co.jp/en/case/010/?hsLang=en) ## Downloads NISSIN ProSOL’s comprehensive catalogue and other resources are available for download. [Download resources here](https://mktg.nissin-mfg.co.jp/en/catalog-form?hsLang=en) ## Contact us If you have any questions or inquiries, please feel free to use the form below to get in touch with us. [Contact us](https://mktg.nissin-mfg.co.jp/en/contact?event_en=HSmktg&hsLang=en) - [Home](https://mktg.nissin-mfg.co.jp/en/) - [Case Study](https://mktg.nissin-mfg.co.jp/en/case/) - [Solution](https://mktg.nissin-mfg.co.jp/en/solution/) - [Product](https://mktg.nissin-mfg.co.jp/en/product/) - [Column](https://mktg.nissin-mfg.co.jp/en/column/) - [Support](https://mktg.nissin-mfg.co.jp/en/support/) - ![logo_NISSINProSOL_2](https://mktg.nissin-mfg.co.jp/hubfs/nissin-mfg/en/website/assets/images/common/logo_NISSINProSOL_2.png) - **NISSIN ProSOL CO., LTD.　Sales Department** 85 Akasaka, Mineyama-cho, Kyotango, Kyoto, 627-0006, JAPAN Tel. ＋81-772-62-8088(Rep.)　Fax. ＋81-772-62-6688 Copyright NISSIN ProSOL CO., LTD. All Rights Reserved.
